Технические характеристики
ПроизводительFANUC
МодельFANUC P-1000iA
КатегорияПромышленные роботы
ControllerR-30iB Plus Controller
Motion range — J1220
Motion range — J2150 degrees
Motion range — J3240 degrees
Motion range — J4145 degrees
Motion range — J51440
Motion range — J61440
Motion range — J71440 degrees
Maximum speed — J1125 (°/s)
Maximum speed — J2125 (°/s)
Maximum speed — J3120 (°/s)
Maximum speed — J4120
Maximum speed — J5200 (°/s)
Maximum speed — J6200 (°/s)
Maximum speed — J7200 (°/s)
Electrical connections — Value (V)380-575 V
Electrical connections — Average power consumption3.5 kW
Environment — Ambient Temperature0-45
General attributes — Payload0-10
General attributes — Robot Payload15 kg
General attributes — Robot Reach2896 mm
General attributes — Axes7
General attributes — Repeatability (ISO9283)±0.08 mm
General attributes — Mechanical weight584 kg
General attributes — J4 Moment(Nm)/Inertia (kgm²)
General attributes — J5 Moment65/ 3.0 (Nm)/Inertia (kgm²)
General attributes — J6 Moment55/ 2.1 (Nm)/Inertia (kgm²)
General attributes — Robot footprint800 x 780
Ценапо запросу
